Oracle 11.2.0.4 单机在 CentOS 7.9 上安装实战

·664 字·4 分钟
Oracle Oracle 11g Oracle 11gR2 CentOS 7 数据库安装 DBA
Greatfinish
作者
Greatfinish
记录 Oracle、PostgreSQL、达梦、Linux、存储与生产环境故障处理经验。
目录

安装介质
#

操作系统包

compat-libstdc++-33-3.2.3-72.el7.x86_64.rpm pdksh-5.2.14-37.el5_8.1.x86_64.rpm

oracle安装介质

p13390677_112040_Linux-x86-64_1of7.zip p13390677_112040_Linux-x86-64_2of7.zip

百度网盘下载

链接: https://pan.baidu.com/s/1-VFR4XFpT-E34Hu_2r5Ztg 提取码: wusd

操作系统设置
#

关闭防火墙
#

systemctl stop firewalld.service
systemctl disable firewalld.service
firewall-cmd --state

关闭selinux
#

setenforce 0
sed -ri 's/SELINUX=enforcing/SELINUX=disabled/' /etc/selinux/config
sestatus

配置Yum源
#

有网络的条件配置源

sed -e "s|^mirrorlist=|#mirrorlist=|g" \
    -e "s|^#baseurl=http://mirror.centos.org/centos/\$releasever|baseurl=http://mirrors.tuna.tsinghua.edu.cn/centos-vault/7.9.2009|g" \
    -e "s|^#baseurl=http://mirror.centos.org/\$contentdir/\$releasever|baseurl=http://mirrors.tuna.tsinghua.edu.cn/centos-vault/7.9.2009|g" \
    -i.bak \
    /etc/yum.repos.d/CentOS-*.repo

没有网络的，配置本地源

mount -o loop /tmp/CentOS-7-x86_64-DVD-2207-02.iso /mnt
cat >> /etc/yum.repos.d/local.repo << "EOF"
[local]
name=local
baseurl=file:///mnt
gpgcheck=0
enabled=1

EOF
yum clean all
yum makecache

配置hosts文件
#

hostnamectl set-hostname oracle11g
cat >> /etc/hosts << "EOF"

192.168.1.8    oracle11g

EOF

配置sysctl.conf
#

cat >> /etc/sysctl.conf << "EOF"

fs.file-max = 6815744
kernel.sem = 250 32000 100 128
kernel.shmmni = 4096
kernel.shmall = 1073741824
kernel.shmmax = 4398046511104
kernel.panic_on_oops = 1
net.core.rmem_default = 262144
net.core.rmem_max = 4194304
net.core.wmem_default = 262144
net.core.wmem_max = 1048576
net.ipv4.conf.all.rp_filter = 2
net.ipv4.conf.default.rp_filter = 2
fs.aio-max-nr = 1048576
net.ipv4.ip_local_port_range = 9000 65500

EOF
/sbin/sysctl -p

memTotal=$(grep MemTotal /proc/meminfo | awk '{print $2}')
totalMemory=$((memTotal / 2048))
shmall=$((memTotal / 4))
if [ $shmall -lt 2097152 ]; then
  shmall=2097152
fi
shmmax=$((memTotal * 1024 - 1))
if [ "$shmmax" -lt 4294967295 ]; then
  shmmax=4294967295
fi
echo $shmall
echo $shmmax

配置limits.conf
#


cat >> /etc/security/limits.conf << "EOF"

oracle soft nofile 1024
oracle hard nofile 65536
oracle soft stack 10240
oracle hard stack 32768
oracle soft nproc 2047
oracle hard nproc 16384
oracle hard memlock 134217728
oracle soft memlock 134217728

EOF

配置 pam.d
#


cat >> /etc/pam.d/login << "EOF"
session    required     pam_limits.so
session    required     /lib64/security/pam_limits.so

EOF

安装所需包
#

yum install -y bc \
binutils \
compat-libcap1 \
compat-libstdc++-33 \
gcc \
gcc-c++ \
elfutils-libelf \
elfutils-libelf-devel \
glibc \
glibc-devel \
ksh \
libaio \
libaio-devel \
libgcc \
libstdc++ \
libstdc++-devel \
libxcb \
libX11 \
libXau \
libXi \
libXtst \
libXrender \
libXrender-devel \
make \
net-tools \
nfs-utils \
smartmontools \
sysstat \
e2fsprogs \
e2fsprogs-libs \
fontconfig-devel \
expect \
unzip \
openssh-clients \
readline* \
psmisc --skip-broken
rpm -e ksh-20120801-144.el7_9.x86_64
rpm -ivh pdksh-5.2.14-37.el5_8.1.x86_64.rpm
rpm -q bc binutils compat-libcap1 compat-libstdc++-33 gcc gcc-c++ elfutils-libelf elfutils-libelf-devel glibc glibc-devel ksh libaio libaio-devel libgcc libstdc++ libstdc++-devel libxcb libX11 libXau libXi libXtst libXrender libXrender-devel make net-tools nfs-utils smartmontools sysstat e2fsprogs e2fsprogs-libs fontconfig-devel expect unzip openssh-clients readline

创建用户
#

groupadd -g 54321 oinstall
groupadd -g 54322 dba
groupadd -g 54323 oper
useradd -u 54321 -g oinstall -G dba,oper oracle
echo "oracle"|passwd --stdin oracle

创建目录
#

mkdir -p /u01/app/oracle/product/11.2.0.4/db_1
chown -R oracle:oinstall /u01
chmod -R 775 /u01

关闭 avahi-deamon 和 NOZEROCONF
#

systemctl stop avahi-daemon.socket
systemctl stop avahi-daemon.service
systemctl disable avahi-daemon.service
systemctl disable avahi-daemon.socket

##关闭 NOZEROCONF
cat <<EOF >>/etc/sysconfig/network
NOZEROCONF=yes
EOF

关闭透明大页和 numa
#

sed -i 's/quiet/quiet transparent_hugepage=never numa=off/' /etc/default/grub
grub2-mkconfig -o /boot/grub2/grub.cfg
init 6
cat /sys/kernel/mm/transparent_hugepage/enabled

安装Oracle软件
#

环境变量设置
#

su - oracle
cat >> /home/oracle/.bash_profile << "EOF"

#Oracle Settings
TMP=/tmp; export TMP
TMPDIR=$TMP; export TMPDIR

ORACLE_HOSTNAME=oracle11g; export ORACLE_HOSTNAME
ORACLE_UNQNAME=orcl; export ORACLE_UNQNAME
ORACLE_BASE=/u01/app/oracle; export ORACLE_BASE
ORACLE_HOME=$ORACLE_BASE/product/11.2.0.4/db_1; export ORACLE_HOME
ORACLE_SID=orcl; export ORACLE_SID
ORACLE_TERM=xterm; export ORACLE_TERM
PATH=/usr/sbin:$PATH; export PATH
PATH=$ORACLE_HOME/bin:$PATH; export PATH
export NLS_LANG="AMERICAN_AMERICA.ZHS16GBK"
export NLS_DATE_FORMAT="yyyy-mm-dd hh24:mi:ss"


LD_LIBRARY_PATH=$ORACLE_HOME/lib:/lib:/usr/lib; export LD_LIBRARY_PATH
CLASSPATH=$ORACLE_HOME/JRE:$ORACLE_HOME/jlib:$ORACLE_HOME/rdbms/jlib; export CLASSPATH

if [ $USER = "oracle" ]; then
  if [ $SHELL = "/bin/ksh" ]; then
    ulimit -p 16384
    ulimit -n 65536
  else
    ulimit -u 16384 -n 65536
  fi
fi

EOF

安装Oracle软件
#

unzip p13390677_112040_Linux-x86-64_1of7.zip
unzip p13390677_112040_Linux-x86-64_2of7.zip
cd database/
export LANG=en_US.UTF-8
export LC_CTYPE=en_US.iso88591
./runInstaller

#root执行
/u01/app/oraInventory/orainstRoot.sh
/u01/app/oracle/product/11.2.0.4/db_1/root.sh

安装中报错ins_emagent.mk解决

cd $ORACLE_HOME/sysman/lib
sed  -i  's/^\(\s*\$(MK_EMAGENT_NMECTL)\)\s*$/\1 -lnnz11/g'  ins_emagent.mk

创建监听和库
#

netca
lnsrctl status
dbca

#数据库创建后，修改部分参数，具体应用再做详细调整
sqlplus / as sysdba
alter system set sec_case_sensitive_logon = false scope=both;
alter system set deferred_segment_creation = false scope=both;
alter profile default limit failed_login_attempts unlimited;
alter profile default limit password_life_time unlimited;
alter system set event='28401 trace name context forever,level 1','10949 trace name context forever,level 1' sid='*' scope=spfile;
alter system set "_optimizer_adaptive_cursor_sharing"=false sid='*' scope=spfile;
alter system set "_optimizer_extended_cursor_sharing"=none sid='*' scope=spfile;
alter system set "_optimizer_extended_cursor_sharing_rel"=none sid='*' scope=spfile;
alter system set "_optimizer_use_feedback"=false sid ='*' scope=spfile;
alter system set "_undo_autotune"=false sid='*' scope=spfile;
alter system set "_optimizer_null_aware_antijoin"=false sid ='*' scope=spfile;
BEGIN
DBMS_AUTO_TASK_ADMIN.DISABLE(
client_name => 'auto space advisor',
operation => NULL,
window_name => NULL);
END;
/

BEGIN
DBMS_AUTO_TASK_ADMIN.DISABLE(
client_name => 'sql tuning advisor',
operation => NULL,
window_name => NULL);
END;
/
